Teflon conveyor belt is generally used to transport products in high temperature environment, such as dried fruit and bread that need to be baked, and also can be used to transport rice flour, cold skin, etc. because it has the characteristics of anti sticking, non-toxic and tasteless, it is relatively common to transport food. Although the advantages of Teflon conveyor belt are very many, the high temperature resistance of Zui can be more than 200 degrees, but sometimes we hear customers' feedback that there is slippage. What is the cause of this?

First of all, we need to know the cause of the conveyor belt slipping, then we can take the right medicine. When the Teflon conveyor belt is in normal operation and the speed is lower than 95% of the roller speed, the friction force between the conveyor belt and the roller is not enough, resulting in sliding phenomenon.

In general, there are many reasons for insufficient friction between the roller and the roller, such as insufficient friction coefficient between the roller and the roller. Of course, there are other aspects will also cause the friction between the conveyor belt and the roller is not enough, small knitting in this will not elaborate.

The reasons for the insufficient tension are insufficient tension travel, insufficient counterweight and too long Teflon conveyor belt. If the initial tension is too small, the tension of the tensioning device is not enough or the tensioning trolley is stuck, the tension at the place where the conveyor belt leaves the drum will be insufficient, which will cause the conveyor belt to slip. The solution is to adjust the tension device, take out the card or increase the counterweight to increase the initial tension.

The friction force between the driving drum and the conveyor belt is not enough, resulting in slipping. Most of the reasons are that there is water on the Teflon conveyor belt or the environment is wet, and the friction coefficient is reduced. The solution is to add some rosin powder on the drum, but pay attention not to put it in by hand, but to use the blowing equipment to blow in, so as to avoid personal accidents.

If the load on the conveyor belt is too large, the motor bearing capacity is exceeded or the starting speed is too fast, it will also cause slipping. The solution is that when the Teflon conveyor belt slips, the materials transported on the conveyor belt should be reduced in time or start slowly; when the conveyor belt does not rotate, the conveyor belt should be stopped immediately and treated.

The above is about the reason why the Teflon conveyor belt skidding is introduced. Basically, it is caused by the above factors. You can refer to it, check and solve it.
