What fields can polyurethane s

We believe that polyurethane synchronous belt is one of the most common types of industrial synchronous belt, which has high tensile resistance. What fields can polyurethane synchronous belt be used in?



Polyurethane synchronous belt is widely used in textile industry, machine tool industry, tobacco manufacturing industry, communication wire and cable industry, light industry, chemical industry, metallurgy industry, precision instrument industry, food transportation and packaging industry, medical equipment and petroleum industry, and has been widely recognized.



Polyurethane synchronous belt installation



1. When installing the synchronous belt, if the center distance of the two pulleys can be moved, the center distance of the pulleys must be shortened first, and then reset after the polyurethane synchronous belt is installed. If there is a tension wheel, first loosen the tension wheel, then install polyurethane synchronous belt, and then install the tension wheel.



2. When installing the polyurethane synchronous belt onto the synchronous belt pulley, do not use too much force or pry the synchronous belt with a screwdriver to prevent the tensile layer in the polyurethane synchronous belt from breaking off in appearance. When designing the belt pulley, it is better to select the structure that the two shafts can move closer to each other. If the structure does not allow, the polyurethane synchronous belt and pulley should be installed on the corresponding shaft together.



3. Control the appropriate initial tension. Too high tension increases the pressure of the top of the belt tooth on the bottom of the belt tooth, shortens the service life of the belt, increases the axial force, and the bearing is easy to be damaged. If the initial tension is too low, the belt will be prone to tooth skipping during operation, the transmission accuracy of the system will be poor, and the vibration and noise will be increased.



4. In polyurethane synchronous belt drive, the parallelism of two pulley axes is required to be relatively high, otherwise the synchronous belt will deviate or even jump out of the pulley. If the axis is not parallel and far away, the pressure will be uneven and the belt teeth will be worn early.



5. The frame supporting the pulley must have enough rigidity, otherwise the two axes will not be parallel when the pulley is running.



The above is the installation and application of polyurethane synchronous belt, I believe you also have a certain understanding. Polyurethane synchronous belt in addition to the ordinary "image", but also can add baffle, guide strip, slotting, etc., welcome new and old customers to inquire.
